Ethernet Slip Rings

• Current: 10*10A,4*2A,12*2A,1*RS422,1*PE, 6*video signal,2*1000M Ethernet
• Voltage: 0~220VACVDC
• Electrical noise: ≤30mΩ(50rpm)
• Dielectric strength: ≥1000V@50Hz (power); ≥300V@50Hz (signal)
• Insulation resistance: ≥1000MΩ@500VDC(power); ≥100MΩ @500VDC (signal)
• Operating speed: 0-300 rpm
• Contact material: Precious metals
• Operating temperature: -20~+60℃
• Through bore size: 70mm
• IP protection grade: IP54

This is through hole slip ring for motion simulator application, through hole size 70mm, housing material is aluminum alloy, video signal and Gigabit Ethernet combined power to deliver in this slip ring. A slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power and signal from a stationary to a rotating structure.
