Specification
| FCN0231G-67A-08-IP68-LL | Specification |
| Fiber type | SM |
| Fiber channel | 8 |
| Wavelength | 1310~1550nm |
| Insertion Loss, max | 4dB |
| Insertion Loss WOW, max | 2dB |
| Rotation Speed, max | 0~150rpm |
| Working life | 200*106 Rotation |
| Torque, max | ≤ 3N*m |
| Compressive strength | ≤ 10MPa |
| Work condition | Under seawater 800-1000m / 1000 hours |
| Lead Wire Length | Rotor: 1000mm, Stator: 1000mm |
| Connector | FC-APC |
