HDMI High Definition USB Slip Rings

• Circuits&Current: 4*5A, 2*USB2.0 ,1*HDMI signal
• Rating voltage: 380VAC
• Dielectric strength: ≥1000V@50hz; ≥100V@50hz
• Insulation resistance: 500 MΩ@500VDC; 20MΩ@100VDC
• Working temperature: -20°C ~ + 60°C
• Working humidity: ≤60%RHProtection gradeIP54
• Working speed: 0~30rpm
• Contact material: Precious metal
• Housing material: Aluminum alloy

The high definition slip ring, it can mix 1-24 channel signal and tiny electric current and multiple installation options. It transfers HD-SDI/video and current signal, it support video standard of 2K@90Hz with less noise, longer life, low torque, stable rotation, electrical noise ≤ 15 mΩ. Our Company slip ring can be customized according to your requirements of various types of HD-SDI slip ring and SDI rotary joint.
