Integrate Pneumatic Slip Rings

• Circuits & Current: 4*5A; 20*signal; 12*USB2.0; 2*1000M Ethernet
• Voltage: 0~220VAC / VDC
• Dielectric strength: ≥1000V@50Hz; ≥300V@50Hz
• Insulation resistance: ≥500MΩ@500VDC; ≥100MΩ@100VDC
• Operating speed: 0-5 rpm
• Contact material: Precious metal
• Housing material: Aluminum alloy + Stainless steel
• IP grade: IP54

Gas channel: 3 channels, G1/8″

• Pressure: ≤ 1.0MPa

The QCN series single passage rotary unions are compact, light weight and corrosion-resistant featuring a stainless steel shaft and hardcoat anodized aluminum housing. The shaft, housing and seal materials and design makes this an excellent solution when transferring water, coolant, hydraulic oil or air/gas from a stationary source to a rotating component. QCN0301-04P-20S-02EG-12U2 including 3 channels for gas (G1/8″, pressure ≤ 1.0MPa ), 4 rings for 5A power, 20 rings for signal, 2 groups for Gigabit Ethernet & 12 groups for USB2.0 signal. The working speed 0~5 rpm with flange installation way. QCN series widely used for rotary tables, injection molding equipment, plastics industry and filling applications etc,.
