Integrated Pneumatic Slip Ring

• Current & Circuits: 4circuits*10A; 25circuits*5A; 1circuit*Gigabit Ethernet signal
• Rating Voltage: 0~24 VAC/VDC
• Dielectric strength: ≥300VAC@50Hz
• Isolation resistance: ≥100MΩ@100VDC
• Contact resistance wave range: ≤30mΩ (50rpm)
• Rotary Torque: ≤3N*m
• Contact material: Precious Metal
• Housing material: SUS 316
• Working temperature: -20°C~+60°C
• Working humidity: 0~ 95%
• Protection Grade: IP54
• Operating speed: 0~10rpm
• Lead wire size: 3*Plugs
• Lead wire length: Rotor – 300mm; Stator – 300mm
• External diameter: Ø130mm
• Installation: Flange installation

Rotary Union

• Channels: 1 channels * gas
• Interface size: Ø12mm tube (G 3/8”)
• Pressure Max: 6.5Bar

QCN0203-04P2-25S-01EG is CENO new product integrated slip ring which combine electrical power, Ethernet signals and one channel pneumatic for industrial automatic system. The integrated pneumatic / hydraulic slip ring is prevent tubes winding problem well, and can provide 1~24 pneumatic passage and hundreds power or signals. As a competent partner for customized rotary joints, most integrated slip ring of CENO products can be modified to meet specific requirements, for more information please contact us.
