| QCN0401 | Specification |
| Channel number | 4 |
| Max pressure | 10MPa |
| Rotating speed | 0-200 rpm |
| Outer diameter | 56mm |
| Connection size | G1/8”,G2/8”,G3/8” are optional |
| Rotating torque | Depends on specific pressures |
| Inlet & Outlet | 4 In & 4 Out |
| Contact material | Precious metal |
| Housing material | Aluminum alloy |
| IP grade | IP54 |
| Working temperature | -20℃~+60℃ |
